Hubbell Wiring Devices HBL7545C 15 Amp 125 Volt 2-Pole 2-Wire NEMA L1-15P Black and White Locking Plug

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL7545C | Codale Part # 110418
$36.29/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
0 available

For Delivery

Out of stock, call for availability
Check your local branch
Primary Spec Sheet PDF Spec Sheet Product Catalog Page Installation Instructions
Locking Devices, Midget Twist-Lock®, Industrial, Male Plug, 15A 125V, 2-Pole 2-Wire Non Grounding, L1-15P, Screw Terminal, Black and White.

Technical Information

Applications
Industrial/Commercial
Conductor Size
14-12 AWG
Cord Type
Portable
Current
15 A
Grounding
Yes
Material
Composite
Mounting Type
Surface
Number of Poles
2 Pole
Number of Wires
3
Size
1.96 in x 1.52 in x 1.52 in
Standard
CSA C22.2 No. 42,Fed. Spec W-C-596,UL 498
Tc Connection
Terminal Screws
Type
Insulgrip, Standard Sized
Voltage
125 Volt
Wattage
1875 Watt
Wire Size
14-12 AWG

Manufacturer Information

Family Brand Name
Hubbell Wiring Device Kellems
Sub Brand
Twist-Lock, Insulgrip

General Product Info

Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product UPC
78358517850
Weight
0.15 lb

Dimensions

Height
1.52 Inch
Length
1.96 Inch
Width
1.52 in

Certifications and Compliance

Country of Origin
USA
Amperage Rating
15 A
Application
Industrial/Commercial
Codale Part No.
110418
Color
Black, White
Cord Type
All Listed Portables
Current Rating
15 A
Dielectric Strength
Withstands 2,000V minimum
Enviromental Conditions
Indoor Dry Unless Protected By Additional Means
Height
1.52 in
Length
1.96 in
Material
Composite
NEMA Rating
L1-15P
Number of Poles
2-Pole
Number of Wires / Conductors
3-Wire
Operating Temperature
Maximum continuous 75°C and minimum -40°C without Impact
Phase
Single Phase
Product Long Description
Locking Devices, Midget Twist-Lock®, Industrial, Male Plug, 15A 125V, 2-Pole 2-Wire Non Grounding, L1-15P, Screw Terminal, Black and White.
Size
1.96 in x 1.52 in x 1.52 in
Type
Plugs
UNSPSC
39121402
Voltage Rating
125 V
Wattage
1875 W
Weight
0.15 lb
Width
1.52 in
Wire Size
#14 AWG to #12 AWG
