Burndy HSB200H12PF2 Heavy Wall Cross-Linked Polyolefin Heat Shrink Tubing, 250-500 kcmil, 1000 V, 1200" L, Flame Retardant

Manufacturer: Hubbell-Burndy | Catalog # HSB200H12PF2 | Codale Part # 1909438
$64.59/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Heavy Wall Cross-Linked Polyolefin Heat Shrink Tubing, 250-500 kcmil, 1000 V, 12.00" L, Flame Retardant

Technical Information

Applications
For Direct Burial
Connection Type
Heavy Wall Tubes
Material
Polyolefin
Shrink Ratio
3 : 1
Type
HS-H-PF, Heavy Wall, Flame Retardant
Voltage
1k Volt

Manufacturer Information

Brand
Burndy
Sub Brand
HEAT SHRINK

General Product Info

12-Digit UPC
781810214879
Product UPC
78181021487
Weight
0.0500 lb

Dimensions

Height
5 Inch
Length
144 Inch
Width
2.00 in

Certifications and Compliance

Country of Origin
Canada
CSA
Yes
Features
  • Type HS-H-PF Is A Heavy Wall, Flame Retardant Heat Shrink Tubing Made Of Cross-Linked Polyolefin, The Shrink Ratio Is 3:1, And The Inside Diameter Is Coated With An Adhesive Sealant To Protect Against Moisture And Corrosion, UL486D Listed For Direct Burial Applications, Accommodates 14 AWG -500 KCMIL Conductors, Operating Temperatures From -55 DEG C To 135 DEG C With A Shrink Temperature Of 120 DEG C, Cut Lengths and 4 Foot Sticks, Inner Diameter Expanded: 2 IN Minimum, Nominal Diameter: 2 IN, Conductor Range: 250 - 500 KCMIL, Material: Cross-Linked Polyolefin, Inner Diameter After Recovery: 0.75 IN Maximum
