Ocal LB67-G 2 Inch Gray PVC Coated Iron Type LB Form7 Rigid Conduit Body Cover

Manufacturer: ABB Ocal | Catalog # LB67-G | Codale Part # 3332475
$370.99/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
4 available

For Delivery

Order by 5:00pm MT for delivery tomorrow
Not available for delivery*
Check your local branch
Primary Spec Sheet PDF Spec Sheet
2 in. Dark Gray PVC Coated Type LB Form 7 Gray Iron Conduit Body and Cover.

Technical Information

Applications
Act as Pull Outlets for Conductors Being Installed
Blade Dimensions
8.3 in L x 3.10 in W x 4.45 in H
Hub Size
2 in
Material
Iron
Size
2 in
Tc Connection
Threaded
Trade Size
2 Inch
Type
Form 7 Conduit Body

Manufacturer Information

Family Brand Name
Ocal
Sub Brand
Ocal

General Product Info

Color
Gray
Finish
PVC Coated
Product UPC
70450839078

Dimensions

Height
4.45 Inch
Length
8.3 Inch
Width
3.1 in
Codale Part No.
3332475
Color
Dark Gray
Finish
PVC Coated
Material
Gray Iron
Product Long Description
2 in. Dark Gray PVC Coated Type LB Form 7 Gray Iron Conduit Body and Cover.
  • Ocal pressure-sealing sleeves on all threaded hubs.
  • Ocal conduit bodies are shipped with a cover and encapsulated stainless steel screws.
  • Covers are coated with a molded flange to seal the conduit body while the conduit body is molded with a flat surface on its opening to seal with the cover.
  • The conduit body and cover are double coated with a nominal .002 in. blue urethane on both the interior and exterior, before PVC coating is applied
  • A minimum of .040 in. PVC coating is bonded to the exterior.
  • Bodies are designed with a flat back, allowing more cubic inch capacity. The flat back also keeps the body more stable during installation, requiring fewer conduit straps.
  • Available in dark gray, white and light blue. Custom colors are also available upon request. Please contact Technical Services-888-862-3289
  • Dimensional values are of uncoated conduit bodies.
  • Connect conduit sections
  • Provide for access to conductors for maintenance and future system changes
  • Provide openings for making splices and taps in conductors
  • Make 90° bends in conduit runs
  • Act as pull outlets for conductors being installed
  • Provide taps for branch conduit runs
  • CSA
  • UL
