3M MNG14-156DMK MNG14-156DMK-A NYLI

Manufacturer: 3M | Catalog # MNG14-156DMK | Codale Part # 3343014

$0.50/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
930 available

For Delivery

Order by 5:00pm MT for delivery tomorrow
Not available for delivery*
Check your local branch

Technical Information

Barrel Length
0.19 in
Barrel Type
Insulation Grip
Conductor Size
14 AWG
Insulation Material
Nylon
Terminal Style
Bullet Snap Plug
Terminal Type
Disconnect

Manufacturer Information

Family Brand Name
3M

General Product Info

Product UPC
05113898137

Dimensions

Length
0.87 Inch
Overall Length
0.87 in
Codale Part No.
3343014
Conductor / Wire Size
16 - 14 AWG
Length
0.87 Inch
Terminal Type
Disconnect
  • Blue nylon-insulated, butted-seam barrel with a funnel-designed, seamless brass sleeve offers easy insertion of wires
  • 1000/case
  • This male disconnect terminal offers excellent holding force
  • Accommodates wire sizes 16 to 14 AWG
  • Mates with 0.156-in wide female tab
  • RoHS 2011/65/EU Compliant
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Rated 300V for building wire
  • Allows for quick and easy disconnect of wires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
