3M MNGI14-250DFK MNGI14-250DFK NYL

Manufacturer: 3M | Catalog # MNGI14-250DFK | Codale Part # 3363427
$0.60/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
Usually ships within 6 to 8 days
Primary Spec Sheet PDF Spec Sheet Product Catalog Page

Technical Information

Material
Nylon
Terminal Size
16 - 14 AWG
Type
Disconnect

Manufacturer Information

Family Brand Name
Scotchlok
Sub Brand
Scotchlok

General Product Info

Product UPC
05400769570

Dimensions

Overall Length
0.83 in
Codale Part No.
3363427
Conductor / Wire Size
16 - 14 AWG
Length
0.83 Inch
Terminal Type
Disconnect
Thickness
0.032 Inch
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Mates with 0.25-in wide male tab
  • 1000/case
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Blue nylon-insulated, butted seam with an interlocking barrel and funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Accommodates wire sizes 16 to 14 AWG
  • Allows for quick and easy disconnect of wires
  • Dents and rolled edges of this female disconnect terminal offer excellent holding force
