3M MNG14-250DFK Nylon Insulated with Insulation Grip Female Disconnect

Manufacturer: 3M | Catalog # MNG14-250DFK | Codale Part # 3393037

$0.48/ea
ea
Adding...
Log in or register to view your price, purchase history, and more!
400 available

For Delivery

Order by 5:00pm MT for delivery tomorrow
Not available for delivery*
Check your local branch

Technical Information

Barrel Length
0.25 in
Barrel Type
Butted
Conductor Size
14 AWG
Insulation Material
Insulation Grip,Nylon
Material
Nylon
Max Operating Temperature
105 C
Terminal Size
16 - 14 AWG
Terminal Style
Standard
Terminal Type
Disconnect
Type
Disconnect

Manufacturer Information

Family Brand Name
Scotchlok
Sub Brand
Scotchlok

General Product Info

Product UPC
05400701774

Dimensions

Length
0.86 Inch
Overall Length
0.86 in
Thickness
0.032 in
Codale Part No.
3393037
Conductor / Wire Size
16 - 14 AWG
Length
0.86 Inch
Terminal Type
Disconnect
Thickness
0.032 Inch
  • Made of durable brass for good conductivity and has corrosion-resistant tin plating
  • Mates with 0.25-in wide male tab
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Blue nylon-insulated, butted-seam barrel with a funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Accommodates wire sizes 16 to 14 AWG
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • 1000/case
  • Allows for quick and easy disconnect of wires
  • Dents and rolled edges of this female disconnect terminal offer excellent holding force
