Brady M-125-075-342 BMP51 BMP53 BMP41 Series PermaSleeve Heat Shrink Polyolefin Wire Marking Sleeve, Cartridge of 80 Each, Maximum Wire Gauge 16

Manufacturer: Brady | Catalog # M-125-075-342 | Codale Part # 3523267
$55.69/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Prop 65 Warning Prop 65 Warning Primary Spec Sheet
PermaSleeve® PS Heat-Shrink Polyolefin (B-342) wire marking sleeves combine speed, ease of use, and permanence to create long-lasting, high quality identification.

Technical Information

Applications
For Cable and Wire Marking
Conductor Size
20-10 AWG
Material
Polyolefin
Max Operating Temperature
275 degrees F
Max Temperature
135 degrees C
Min Operating Temperature
-67 degrees F
Min Temperature
-55 degrees C
Shrink Ratio
3:1
Type
Heat Shrink Tubing
Wire Size
22-16 AWG

Manufacturer Information

Brand
Brady Corporation
Sub Brand
PermaSleeve®

General Product Info

12-Digit UPC
662820999966
Color
Black/White
Finish
Matte
Product UPC
66282099996
Qty per Row
1
Used With
BMP®41 Label Printer, BMP®51 Label Maker, BMP®53 Label Maker Printers

Dimensions

Diameter
1/8 Inch
Height
0.235 Inch
Length
0.235 Inch
Roll Width
0.75 in
Width
3/4 in

Certifications & Compliance

Prop 65 Warning
Y
Features
  • 3:1 heat shrinkable sleeve fit snugly around wires for maximum insulation protection and permanent identification
  • Fade-resistant and smudge-proof for superior aesthetic appearance
  • Cold resistant and flame-retardant with an operating temperature of -67°F to 275°F (-55°C to 135°C)
  • All-in-one cartridge includes label supply and R4300 Series ribbon
