Manufacturer 3M
Mfg Catalog # 2242-1-1/2x15FT
Codale Part # 50306


Scotch® Tape 2242 is a linerless 30-mil thick, general purpose, electrical rubber tape that's suitable for bus bar insulation and moisture sealing of cable ends. The high-voltage, flame-retardant tape ensures excellent tacking with its self-fusing, ethylene propylene rubber resin adhesive.

Scotch® Tape 2242 is designed for terminating and splicing wires and cables and maintains stability in temperatures up to 194 degrees F (90 degrees C). This weather-resistant tape has excellent physical and electrical properties and provides a moisture seal and void-free buildups. The highly conformable tape has a flexible, rubber backing that optimally resists UV rays and heat. ASTM Approved and RoHS 2011/65/EU Compliant.

  • Rubber-resin adhesive provides excellent adherence while self-fusing, ethylene propylene rubber backing resists UV rays and heat.
  • Tape measures 1-1/2 in x 15 ft x 30 mil
  • Comes in black color
  • ASTM Approved and RoHS 2011/65/EU Compliant
  • 1 roll/carton, 12 rolls/case


  • 3M ID: 80610922967
  • Adhesive Material: Rubber Resin
  • Agency Approvals: ASTM D-4388 Type 1, 2 & 3, HH-I-553C
  • Backing Material: Rubber
  • Brand: 3M
  • Breaking Strength: 7.5 lb/in
  • Case Quantity: 100 Rolls
  • Color: Black
  • Dielectric Strength (V/mil): 750 V/mil
  • Emergency Overload Temperature (Celsius): 130°C
  • Emergency Overload Temperature (Fahrenheit): 266°F
  • Family: 3M™ Linerless Splicing Compound 2242
  • Length: 15 Linear Foot
  • Material: Self-fusing EPR
  • Operating Temperature (Celsius): 90 °C
  • Operating Temperature (Fahrenheit): 194 °F
  • Product Markets: Electrical Construction, Electrical MRO, Power Distribution
  • Product Type: Rubber and Splicing Tapes
  • RoHS 2011/65/EU Compliant: RoHS 2011/65/EU Compliant, Yes
  • RoHS EU Comments: RoHS 2011/65/EU compliant without exemption
  • Rolls per Carton: 1
  • Rolls per Case: 12
  • Tape Grade: Premium
  • Tape Type: Medium Grade Rubber Tape
  • Tensile Strength: 250 Pound-Force Per Square Inch
  • Tensile Strength lb/in (N/100 mm): 7.5 (131)
  • Thickness: 30 mil
  • Trademark: Scotch
  • Width: 1.5 Inch

Legal Disclaimer

  • Manufacturing Origin: USA
  • The designation that a product is Manufactured in the USA means the product undergoes substantial transformation in one of our U.S. Manufacturing plants. Some products contain imported components.
  • Note: 3M products offered on a government contract that require country of origin representation must be certified by 3M Trade Compliance. Contact customer service at 800-245-3573 to request a certificate.


UPC 05400741323
Codale Part No. 50306
Material Self-fusing EPR
Color Black
Length 15 Linear Foot
Width 1.5 Inch
Thickness 30 mil
Tensile Strength 250 Pound-Force Per Square Inch
Item Long Description Linerless Splicing Compound 1 1/2" x 15'
Length 15 LF
Width 1.5 in
Size 1.5 in x 15 ft
Color Black
Type Splicing
Thickness 30 mil
Material Self-fusing EPR
Backing Material Rubber
Applications General Purpose
Family Brand Name 3M
Tensile Strength 250 Pound-Force Per Square Inch
Sub Brand Scotch
Product Type Rubber And Splicing Tapes
