3M MH14BCK BUTT CONNECTORS - HEAT SHRINK

Manufacturer	3M
Mfg Catalog #	MH14BCK
Codale Part #	477385

Overview

UPC	05400706319
Product Description	SEAMLESS BUTT HEAT SHRINK CONNECTOR (BULK)
Catalog Description	3M Scotchlok Color-Coded Heat Shrink Butt Connector ensures an ideal fit with great performance. The seamless barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221 degrees F (105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.
Codale Part No.	477385
Color	Blue
Length	1.3 Inch
Thickness	0.031 Inch
Conductor / Wire Size	16 - 14 AWG
Connection Type	Butt
Terminal Type	Butt Connectors
Item Long Description	Corrosion resistance to water, salt, steam and other related contaminantsSeamless barrel uses blue pre-insulated, heat shrink tubing and ensures a secure fit while offering reliable performanceWhen crimped and shrunk, pre-insulated adhesive-lined polyolefin offers seal resistance to water and saltAccommodates wire sizes 16 to 14 AWGWhen crimped and shrunk, pre-insulated adhesive-lined polyolefin offers seal resistance to water and saltMaximum operating temperature of 221F (105C)UL Listed, CSA Certified and RoHS 2011/65/EU Compliant600V-rated for building wire and 1000V for signs, fixtures or luminaires
MDM Pkg GTiN	00054007063193
Length	1.3 in
Color	Blue
Type	Standard
Thickness	0.031 in
Barrel Type	Seamless
Material	Heat Shrink
Terminal Style	Standard
Terminal Type	Butt
Conductor Size	14-16 AWG
Family Brand Name	3M
Insulation Material	Heat Shrink
Terminal Size	16 - 14 AWG
Barrel Length	0.3 in
Sub Brand	Scotchlok
Max Operating Temperature	105 C
Overall Length	1.3 in
