ABB ST202M-C20 MCB ST200M 2P C 20AUL1077
Already a Customer? Log in to view your pricing
Manufacturer ABB Thomas & Betts
Mfg Catalog # ST202M-C20
Codale Part # 4306419
ABB ST202M-C20 MCB ST200M 2P C 20A UL1077


UPC 88861480734
Family Brand Name Thomas & Betts
Item Long Description The ST200M miniature circuit breaker provides supplementary protection acc. to UL 1077 up to 480 Y/277 VAC and 125 VDC. With a broad range of options and approvals acc. to the international standards UL, CSA and IEC, the ST 200 M is ideal for multiple applications and markets. It is also fully compatible with System pro M compact accessories. High performance MCB with interrupt rating up to 10 kA. Certified for AC and DC use acc. to UL 1077 and CSA 22.2 No. 235. Suitable for many applications due to a wide range of product types and available accessories. High calibration temperature of 40 C for reduced derating in ICP applications. Short-circuit current rating (SC) U2 enables continuous high level short circuit protection. Laser printing provides clear product information on device. Clear contact position indication in red/green (real CPI). Unique, patented twin terminal for wiring up to 35 mm with captive screws. Field wiring available for most types. Robust thermoplastic housing material for better protection against external influences.
Conductor Size 35 mm Solid/Strande
Mounting Type DIN Rail
Temperature Rating -25 to 55 C
Housing Material Thermoplastic
Actuator Toggle
Blade Dimensions 35 mm W x 69 mm D x
Environmental Conditions 28 Cycles with 90 -
Trip Type C-Curve, Thermal, El
Number of Poles 2 Pole
Interrupt Rating 10 kA
Trip Range 1.03 - 1.25 A Therma
