A-B 1769-IF4XOF2 COMBO ANALOG INPUT AND OUTPUT CARD (LOW RESOLUTION)
$711.00/ea
Usually ships within 10 to 16 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen Bradley / Rockwell
Mfg Catalog # 1769-IF4XOF2
Codale Part # 488416
A-B 1769-IF4XOF2 COMBO ANALOG INPUT AND OUTPUT CARD (LOW RESOLUTION)

Overview

UPC 61259828621
Catalog Description Combination Module,CompactLogix,Analog,6 Point,4 Current or Voltage Input,2 Current or Voltage Output,8 Bits Resolution
Codale Part No. 488416
Product Long Description Combination Module, CompactLogix, Analog, 6 Point, 4 Current or Voltage Input, 2 Current or Voltage Output, 8 Bits Resolution
Type Analog Combo Module
Sub Brand CompactLogix
Mounting DIN Rail / Panel mount
Width 35mm, 1.38"
Enclosure Specification None (open-style)
Height 118mm, 4.65"
Operating Temperature 0...60 °C (32...140 °F)
Depth 87mm, 3.43"
Display Type Status LEDs
Input Signal 0...10V, 0...20 mA
Output Signal 0...10V, 0...20 mA
Isolation 500V AC or 710V DC for 1 minute (qualification test), group to bus. 30V AC/30V DC working voltage (IEC Class 2 reinforced insulation)
Product Short Description 8 Bit Resolution, High Speed 4 In/2 Out Anlg. Comb
MDM Item Long Description Combination Module,
MDM Pkg GTiN 00612598286218
Width 1.38 in
Operating Temperature 0 To 60 C
Type Analog Combo
Mounting Type DIN Rail,Panel Mount
Depth 3.43 in
Height 4.65 in
Family Brand Name Allen Bradley
Number of Channels 6
Output 2 Analog
Power Supply 120 mA at 5VDC, 160
Blade Dimensions 35 mm W x 87 mm D x
Output Signal 010V, 020 mA
Sub Brand CompactLogix
