A-B 1769-IR6 6 CHANNEL RTD COMPACT MODULE
$1,270.00/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen Bradley / Rockwell
Mfg Catalog # 1769-IR6
Codale Part # 484191
A-B 1769-IR6 6 CHANNEL RTD COMPACT MODULE

Overview

UPC 61132031441
Catalog Description Input Module,CompactLogix,6 Point, RTD or Other Resistance Inputs,Input Types Platinum 385 or Platinum 3916 or 1200 Ohm Nickel 672 or 1200 Ohm Nickel 618 or 604 Ohm Nickel Iron 518
Codale Part No. 484191
Product Long Description Input Module, CompactLogix, 6 Point, RTD or Other Resistance Inputs, Input Types Platinum 385 or Platinum 3916 or 1200 Ohm Nickel 672or 1200 Ohm Nickel 618 or 604 Ohm Nickel Iron 518
Type Analog Input Module
Sub Brand CompactLogix
Mounting DIN Rail / Panel mount
Width 35mm, 1.38"
Enclosure Specification None (open-style)
Height 118mm, 4.65"
Operating Temperature 0...60 °C (32...140 °F)
Depth 87mm, 3.43"
Display Type Status LEDs
Input Signal 0...150 O, 0...500 O, 0...1000 O, 0...3000 O
Isolation 720V DC for 1 minute, optical and magnetic (qualification), channel to bus. 30V AC/30V DC working voltage (IEC Class 2 reinforced insulation)
Product Short Description 6 Channel RTD/Resistance Input Module
MDM Item Long Description Input Module, Compac
MDM Pkg GTiN 00611320314410
Width 1.38 in
Operating Temperature 0 To 60 C
Type RTD/Resistance
Mounting Type DIN Rail,Panel Mount
Depth 3.43 in
Height 4.65 in
Family Brand Name Allen Bradley
Number of Channels 6
Tc Connection Plug-in
Power Supply 100 mA at 5VDC, 45 m
Blade Dimensions 35 mm W x 87 mm D x
Sub Brand CompactLogix
