A-B 802T-NPTP1 LIMIT SWITCH
$190.21/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen Bradley / Rockwell
Mfg Catalog # 802T-NPTP1
Codale Part # 100615
A-B 802T-NPTP1 LIMIT SWITCH

Categories

Overview

UPC 66246808008
Catalog Description Plug-In Oiltight Limit Switch,Metal,10 A Standard Energy,Rotary Lever Arm,4 Circuits,Standard Contacts,2 Normally Open Contacts,2 Normally Closed Contacts,Standard Low Temprature, -18°C,110 °C High Temp Limit,Snap Acting,Clockwise & Counter Clockwise,Neutral Position,Switch Body,NEMA Style Standard Mounting,Not Direct Acting,802T Plug-in Style,Clockwise 2.5 lb in, Countercl,13 Degree Angle,7 Degree Angle,A300,186
Codale Part No. 100615
Product Long Description Plug-In Oiltight Limit Switch, Metal, 10 A Standard Energy, Rotary Lever Arm, 4 Circuits, Standard Contacts, 2 Normally Open Contacts, 2 Normally Closed Contacts, Standard Low Temprature, -18°C, 110 °C High Temp Limit, Snap Acting, Clockwise & Counter Clockwise, Neutral Position, Switch Body, NEMA Style Standard Mounting, Not Direct Acting, 802T Plug-in Style, Clockwise 2.5 lb in, Countercl, 13 Degree Angle, 7 Degree Angle, A300, 186
Type Oiltight Limit Switches
Product Short Description Limit Switch, NEMA Type 4 and 13 Oiltight Construction, Plug-In, Lever Type, Spring Return, Neutral Position, 4-Circuit, Head Only
Item Long Description Metal Plug-In Oiltight Limit Switch
MDM Pkg GTiN 00662468080088
Size 802T Plug-in Style
Operating Temperature -18 C
Type Oiltight
Material Metal
Applications Switch Body
Mounting Type Horizontal, Standard
Connection Type Plug-In
Temperature Rating -18 to 110 C
Family Brand Name Allen Bradley
Tc Connection Cable Length Not App
Actuator Rotary Lever Arm
Contact Configuration 2 NO, 2 NC
Blade Dimensions 46.24 mm L x 41.4 mm
Number of Circuits 4
Contact Rating A300
Number of Poles 2 Pole
Enclosure Metal
Action Snap
Standard CCC,CE,CSA,KC,UL
