Bussmann Series FRN-R-300 Class RK5 Fusetron Dual Element
Product image thumbnail 0
Product image thumbnail 1
$94.99/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Eaton Bussmann
Mfg Catalog # FRN-R-300
Codale Part # 44469

Specifications

  • Fuse Indicator: Non Indicating
  • Interrupt Rating: 200 kAIC at 250 Vac, 20 kAIC at 125 Vdc
  • Type: Current-limiting, time delay
  • Number Of Elements: Dual
  • Connection: Blade end X blade end
  • Response Time: 10s at 500%
  • Class: Class RK5
  • Voltage Rating: 250 Vac, 125 Vdc
  • Application: Combination starters, motor control centers, machinery disconnects, power panelboards
  • Amperage Rating: 300 A
  • Diameter: 2.38 IN
  • Packaging Type: Standard

General

  • UPC: 051712507516
  • Product Length/Depth: .4 IN
  • Product Height: .3 IN
  • Product Width: .3 IN
  • Product Weight: .05 LB
  • Warranty: Not Applicable
  • Compliances: CE Marked

Overview

UPC 05171250751
Codale Part No. 44469
Type Current-limiting, time delay
Application Combination starters, motor control centers, machinery disconnects, power panelboards
Voltage Rating 250 Vac, 125 Vdc
Length .81 IN
Amperage Rating 300A
Connection Type Blade end X blade end
Width .81 IN
Height 3 IN
Interrupt Rating 200 kAIC at 250 Vac, 20 kAIC at 125 Vdc
Diameter 2.38 IN
Weight 1.95 LB
Class Class RK5
Response Time 10s at 500%
Packaging Type Standard
Item Long Description Eaton Bussmann series FRN-R fuse, 250 Vac, 125 Vdc, 300A, 200 kAIC at 250 Vac, 20 kAIC at 125 Vdc, Non Indicating, Current-limiting, time delay, Blade end X blade end, Class RK5
MDM Pkg GTiN 00051712507516
Length .4 in
Size 2.38 In Diameter X 8.63 In Length
Voltage 250 Volt
Type Current Limiting,Time Delay
Diameter 2.38 in
Applications Ind Facilities & Factories - Facility: Safety and Security Systems
Height .3 in
Weight .05 lb
Connection Type Blade
Family Brand Name Bussmann Series
Class RK5
Tc Connection Blade end X blade end
Amperage 300 Amp
Response Time 10 seconds at 500%
End Type Blade
Interrupt Rating 20 kA
Sub Brand Bussmann Series
Blade Dimensions 0.4000 IN X 0.3000 IN X 0.3000 IN
Standard CE,CSA C22.2,UL 248-12
Element Dual
