FRS-R Fusetron | Codale Electric Supply

UPC	05171250830
Product Description	DUAL-ELEMENT, FRS-R, CLASS RK5, 15 AMP
Codale Part No.	44491
Type	Current-limiting, time delay
Application	Combination starters, motor control centers, machinery disconnects, power panelboards
Voltage Rating	600 Vac, 300 Vdc
Length	.81 IN
Amperage Rating	15A
Connection Type	Ferrule end X ferrule end
Width	.81 IN
Height	5 IN
Interrupt Rating	200 kAIC at 600 Vac, 20 kAIC at 300 Vdc
Diameter	.81 IN
Weight	.15 LB
Class	Class RK5
Response Time	10s at 500%
Packaging Type	Standard
Catalog Description	FUSETRON DUAL ELEMENT FUSE CLASS RK5
Product Short Description	FRS-R Fusetron
Item Long Description	Eaton Bussmann series FRS-R fuse, 600 Vac, 300 Vdc, 15A, 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc, Non Indicating, Current-limiting, time delay, Ferrule end X ferrule end, Class RK5 - FRS-R-15
MDM Pkg GTiN	00051712508308
Length	.81 in
Width	.81 in
Size	0.81 In Diameter X 5.00 In Length
Voltage	300 Volt
Type	Current Limiting,Time Delay
Diameter	.81 in
Applications	Ind Facilities & Factories - Facility: Safety and Security Systems
Height	5 in
Weight	.15 lb
Standard	CE,CSA,UL 248-12
Connection Type	Ferrule
Family Brand Name	Bussmann Series
Class	Class RK5
Tc Connection	Ferrule end X ferrul
Amperage	15 Amp
Response Time	10 seconds at 500%
End Type	Ferrule
Interrupt Rating	20 kA
Element	Dual
Sub Brand	Bussmann Series
Blade Dimensions	5.0000 IN X 0.8100 I
MDM PRODUCT KEYWORD	TRS15R, FLSR015, FLSR015ID, ECSR15
