Manufacturer | Eaton Bussmann |
---|---|
Mfg Catalog # | FRS-R-50 |
Codale Part # | 44515 |
UPC | 05171250838 |
Product Description | DUAL-ELEMENT, FRS-R, CLASS RK5, 50 AMP |
Codale Part No. | 44515 |
Type | Current-limiting, time delay |
Application | Combination starters, motor control centers, machinery disconnects, power panelboards |
Voltage Rating | 600 Vac, 250 Vdc |
Length | 1.6 IN |
Amperage Rating | 50A |
Connection Type | Ferrule end X ferrule end |
Width | 1.6 IN |
Height | 5.5 IN |
Interrupt Rating | 200 kAIC at 600 Vac, 20 kAIC at 250 Vdc |
Diameter | 1.06 IN |
Weight | .35 LB |
Class | Class RK5 |
Response Time | 10s at 500% |
Packaging Type | Standard |
Catalog Description | FUSETRON DUAL ELEMENT FUSE CLASS RK5 |
Product Short Description | FRS-R Fusetron |
Item Long Description | Eaton Bussmann series FRS-R fuse, 600 Vac, 250 Vdc, 50A, 200 kAIC at 600 Vac, 20 kAIC at 250 Vdc, Non Indicating, Current-limiting, time delay, Ferrule end X ferrule end, Class RK5 - FRS-R-50 |
MDM Pkg GTiN | 00051712508384 |
Length | 13.38 in |
Width | 1.6 in |
Size | 1.06 In Diameter X 5.50 In Length |
Voltage | 250 Volt |
Type | Current Limiting,Time Delay |
Diameter | 1.06 in |
Applications | Ind Facilities & Factories - Facility: Safety and Security Systems |
Height | 2.88 in |
Weight | 3.6 lb |
Connection Type | Ferrule |
Family Brand Name | Bussmann Series |
Class | RK-5 |
Tc Connection | Ferrule end X ferrul |
Amperage | 50 Amp |
Response Time | 10 S at 500% |
End Type | Ferrule |
Interrupt Rating | 20 kA |
Sub Brand | Bussmann Series |
Blade Dimensions | 13.3800 IN X 2.8800 |
MDM PRODUCT KEYWORD | ECSR50, FLSR050ID, FLSR050, TRS50R |
