Manufacturer | Eaton Bussmann |
---|---|
Mfg Catalog # | FRS-R-6 |
Codale Part # | 44516 |
UPC | 05171250857 |
Product Description | DUAL-ELEMENT, FRS-R, CLASS RK5, 6 AMP |
Codale Part No. | 44516 |
Type | Current-limiting, time delay |
Application | Combination starters, motor control centers, machinery disconnects, power panelboards |
Voltage Rating | 600 Vac, 300 Vdc |
Length | .81 IN |
Amperage Rating | 6A |
Connection Type | Ferrule end X ferrule end |
Width | .81 IN |
Height | 5 IN |
Interrupt Rating | 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc |
Diameter | .81 IN |
Weight | .15 LB |
Class | Class RK5 |
Response Time | 10s at 500% |
Packaging Type | Standard |
Catalog Description | FUSETRON DUAL ELEMENT FUSE CLASS RK5 |
Product Short Description | FRS-R Fusetron |
Item Long Description | Eaton Bussmann series FRS-R fuse, 600 Vac, 300 Vdc, 6A, 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc, Non Indicating, Current-limiting, time delay, Ferrule end X ferrule end, Class RK5 - FRS-R-6 |
MDM Pkg GTiN | 00051712508575 |
Length | 5 in |
Size | 0.81 In Diameter X 5.00 In Length |
Voltage | 300 Volt |
Type | Current Limiting,Time Delay |
Diameter | .81 in |
Applications | Ind Facilities & Factories - Facility: Safety and Security Systems |
Height | .81 in |
Weight | .15 lb |
Connection Type | Ferrule |
Family Brand Name | Bussmann Series |
Class | RK5 |
Tc Connection | Ferrule end X ferrul |
Amperage | 6 Amp |
Response Time | 10 S at 500% |
End Type | Ferrule |
Interrupt Rating | 20 kA |
Sub Brand | Bussmann Series |
Blade Dimensions | 5.0000 IN X 0.8100 I |
MDM PRODUCT KEYWORD | TRS6R, FLSR006, FLSR006ID |
