BUSSMANN FRSR8 600K DUAL-ELEMENT RK5 TIME-DELAY FUSE
Product image thumbnail 0
Product image thumbnail 1
$13.77/ea
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Eaton Bussmann
Mfg Catalog # FRS-R-8
Codale Part # 44523
BUSSMANN FRSR8 600K DUAL-ELEMENT RK5 TIME-DELAY FUSE

Overview

UPC 05171250826
Product Description DUAL-ELEMENT, FRS-R, CLASS RK5, 8 AMP
Codale Part No. 44523
Type Current-limiting, time delay
Application Combination starters, motor control centers, machinery disconnects, power panelboards
Voltage Rating 600 Vac, 300 Vdc
Length .81 IN
Amperage Rating 8A
Connection Type Ferrule end X ferrule end
Width .81 IN
Height 5 IN
Interrupt Rating 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc
Diameter .81 IN
Weight .15 LB
Class Class RK5
Response Time 10s at 500%
Packaging Type Standard
Catalog Description FUSETRON DUAL ELEMENT FUSE CLASS RK5
Product Short Description FRS-R Fusetron
MDM Item Long Description 8A 600V Class RK5 Fu
MDM Pkg GTiN 00051712508261
Length 7.88 in
Width .81 in
Size 0.81 In Diameter X 5.00 In Length
Voltage 300 Volt
Type Time Delay,Current Limiting
Diameter .81 in
Applications Combination Starters, Motor Control Centers, Machinery Disconnects, Power Panelboards
Height 1.11 in
Weight .4 lb
Standard UL 248-12,CSA,CE
Connection Type Ferrule
Family Brand Name Eaton
Class Class RK5
Tc Connection Ferrule End X Ferrul
Amperage 8 Amp
Response Time 10 seconds at 500%
End Type Ferrule
Interrupt Rating 200 kA
Element Dual
Sub Brand Fusetron
