Manufacturer | Eaton Bussmann |
---|---|
Mfg Catalog # | LP-CC-15 |
Codale Part # | 44091 |
UPC | 05171211530 |
Product Description | LOW PEAK CC TIME DELAY |
Codale Part No. | 44091 |
Type | Current-limiting, Time-delay |
Application | Specialized circuits and industrial control |
Voltage Rating | 600 Vac, 150 Vdc |
Length | .41 IN |
Amperage Rating | 15A |
Connection Type | Ferrule end X ferrule end |
Width | .41 IN |
Height | 1.5 IN |
Interrupt Rating | 200 kAIC at 600 Vac, 20 kAIC at 150 Vdc |
Diameter | .40625 IN |
Weight | .15 LB |
Class | Class CC |
Response Time | 12s at 200% |
Packaging Type | Standard |
Catalog Description | LOW PEAK CC TIME DELAY |
Product Short Description | Low Peak Fuse |
Item Long Description | Eaton Bussmann Series LP-CC Fuse,Low Peak Fuse,Current-Limiting,time delay,15 A,600 Vac,150 Vdc,200 kAIC at 600 Vac,20 kAIC at 150 Vdc,Class CC,12s at 200%,Dual element,Melamine tube,Ferrule end X ferrule end connection,RoHS Compliant |
MDM Pkg GTiN | 00051712115308 |
Length | 1.5 in |
Width | .41 in |
Size | 13/32 In Diameter X 1-1/2 In Length |
Voltage | 150 Volt |
Type | Current Limiting,Time-Delay |
Diameter | .406 in |
Material | Melamine tube |
Applications | Ind Facilities & Factories - Facility: Safety and Security Systems |
Height | .41 in |
Weight | .15 lb |
Connection Type | Ferrule |
Family Brand Name | Bussmann Series |
Class | CC |
Tc Connection | Ferrule end x ferrul |
Amperage | 15 Amp |
Response Time | 12 S at 200% |
End Type | Ferrule |
Interrupt Rating | 20 kA |
Sub Brand | Bussmann Series |
Blade Dimensions | 1.5000 IN X 0.4100 I |
MDM PRODUCT KEYWORD | ATDR15, CCMR015, EDCC15 |
