Manufacturer | Eaton Bussmann |
---|---|
Mfg Catalog # | LP-CC-25 |
Codale Part # | 44094 |
UPC | 05171218028 |
Product Description | LOW PEAK CC TIME DELAY |
Codale Part No. | 44094 |
Catalog Description | LOW PEAK CC TIME DELAY |
Item Long Description | Eaton Bussmann series LP-CC fuse, Rejection Style, 600 Vac, 300 Vdc, 25A, 200 kAIC at 600 Vac, 20 kAIC at 300 Vdc, Non Indicating, Current-limiting, Time-delay, Ferrule end X ferrule end, Class CC, Melamine tube |
MDM Pkg GTiN | 00051712180283 |
Length | .41 in |
Width | .41 in |
Size | 13/32 In Diameter X 1-1/2 In Length |
Type | Current Limiting,Time-Delay |
Diameter | .406 in |
Material | Melamine tube |
Applications | Ind Facilities & Factories - Facility: Safety and Security Systems |
Height | 1.5 in |
Weight | .15 lb |
Connection Type | Ferrule |
Family Brand Name | Bussmann Series |
Class | CC |
Tc Connection | Ferrule end x ferrul |
Amperage | 25 Amp |
Response Time | 12 S at 200% |
End Type | Ferrule |
Interrupt Rating | 20 kA |
Sub Brand | Bussmann Series |
Voltage | 600//300 VAC//VDC |
Blade Dimensions | 0.4100 IN X 0.4100 I |
MDM PRODUCT KEYWORD | CCMR025, ATDR25 |
