Low Peak Fuse | Codale Electric Supply

UPC	05171218032
Product Description	LOW PEAK CC TIME DELAY
Codale Part No.	44097
Type	Current-limiting, Time-delay
Application	Specialized circuits and industrial control
Voltage Rating	600 Vac, 150 Vdc
Length	.41 IN
Amperage Rating	4A
Connection Type	Ferrule end X ferrule end
Width	.41 IN
Height	1.5 IN
Interrupt Rating	200 kAIC at 600 Vac, 20 kAIC at 150 Vdc
Diameter	.40625 IN
Weight	.15 LB
Class	Class CC
Response Time	12s at 200%
Packaging Type	Standard
Catalog Description	LOW PEAK CC TIME DELAY
Product Short Description	Low Peak Fuse
Item Long Description	4A 600V Class CC Low Peak Time Delay Fuse
MDM Pkg GTiN	00051712180320
Length	1.5 in
Width	.41 in
Size	13/32 In Diameter X 1-1/2 In Length
Voltage	150 Volt
Type	Current Limiting,Time-Delay
Diameter	.406 in
Material	Melamine Tube
Applications	Ind Facilities & Factories - Facility: Safety and Security Systems
Height	.41 in
Weight	.15 lb
Standard	CE,CSA,UL 248-4
Connection Type	Ferrule
Family Brand Name	Bussmann Series
Class	CC
Tc Connection	Ferrule end x ferrul
Amperage	4 Amp
Response Time	12 seconds at 200%
End Type	Ferrule
Interrupt Rating	20 kA
Element	Dual
Sub Brand	Bussmann Series
Blade Dimensions	1.5000 IN X 0.4100 I
MDM PRODUCT KEYWORD	CCMR004, EDCC4, ATDR4
