Bussmann Series LP-CC-8 Low Peak Time Delay Fuse
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$23.97/ea
Usually ships within 6 to 10 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Eaton Bussmann
Mfg Catalog # LP-CC-8
Codale Part # 48113

Specifications

  • Fuse Indicator: Non Indicating
  • Special Features: Rejection Style
  • Interrupt Rating: 200 kAIC at 600 Vac, 20 kAIC at 150 Vdc
  • Number Of Elements: Dual
  • Connection: Ferrule end X ferrule end
  • Quantity: Carton: 10
  • Response Time: 12s at 200%
  • Material Type: Melamine tube
  • Amperage Rating: 8A
  • Type: Current-limiting, Time-delay
  • Class: Class CC
  • Voltage Rating: 600 Vac, 150 Vdc
  • Application: Specialized circuits and industrial control
  • Diameter: .40625 IN
  • Packaging Type: Standard

General

  • UPC: 051712180399
  • Product Length/Depth: 1.5 IN
  • Product Height: .41 IN
  • Product Width: .41 IN
  • Product Weight: .15 LB
  • Warranty: Not Applicable
  • Compliances: CE Marked

Overview

UPC 05171218039
Codale Part No. 48113
Type Current-limiting, Time-delay
Application Specialized circuits and industrial control
Voltage Rating 600 Vac, 150 Vdc
Length .41 IN
Amperage Rating 8A
Connection Type Ferrule end X ferrule end
Width .41 IN
Height 1.5 IN
Interrupt Rating 200 kAIC at 600 Vac, 20 kAIC at 150 Vdc
Diameter .40625 IN
Weight .15 LB
Class Class CC
Response Time 12s at 200%
Packaging Type Standard
Item Long Description Eaton Bussmann Series LP-CC Fuse,Low Peak Fuse,Current-Limiting,time delay,8 A,600 Vac,150 Vdc,200 kAIC at 600 Vac,20 kAIC at 150 Vdc,Class CC,12s at 200%,Dual element,Melamine tube,Ferrule end X ferrule end connection,RoHS Compliant
Length 1.5 in
Width .41 in
Size 13/32 In Diameter X 1-1/2 In Length
Voltage 150 Volt
Type Current Limiting,Time-Delay
Diameter .406 in
Material Melamine Tube
Applications Ind Facilities & Factories - Facility: Safety and Security Systems
Height .41 in
Weight .15 lb
Standard CE,CSA,UL 248-4
Connection Type Ferrule
Family Brand Name Bussmann Series
Class CC
Tc Connection Ferrule end x ferrule end
Amperage 8 Amp
Response Time 12 seconds at 200%
End Type Ferrule
Interrupt Rating 20 kA
Element Dual
Sub Brand Bussmann Series
Blade Dimensions 1.5000 IN X 0.4100 IN X 0.4100 IN
