Manufacturer | Eaton Bussmann |
---|---|
Mfg Catalog # | LPN-RK-20SP |
Codale Part # | 44560 |
UPC | 05171253834 |
Codale Part No. | 44560 |
Type | Current-limiting, Time-delay |
Application | Large distribution switchboards, power panelboards, motor control centers |
Voltage Rating | 250 Vac, 125 Vdc |
Length | 2 IN |
Amperage Rating | 20A |
Connection Type | Ferrule end X ferrule end |
Width | .56 IN |
Height | .56 IN |
Interrupt Rating | 300 kAIC at 250 Vac, 100 kAIC at 125 Vdc |
Diameter | .56 IN |
Weight | .5 LB |
Class | Class RK1 |
Response Time | 8s at 500% |
Packaging Type | Standard |
Catalog Description | LOW PEAK DUAL ELEMENT |
Product Short Description | Low Peak Fuse |
Item Long Description | Eaton Bussmann Series LPN-RK Fuse, Low Peak Fuse, Current-Limiting, time delay, Electrically isolated end cap, 20 A, 250 Vac, 125 Vdc, 300 kAIC at 250 Vac, 100 kAIC at 125 Vdc, Class RK1, 8s at 500% response time, Dual element |
MDM Pkg GTiN | 00051712538343 |
Length | 2 in |
Width | .56 in |
Size | 0.56 In Diameter X 2.00 In Length |
Voltage | 125 Volt |
Type | Current Limiting,Time-Delay |
Diameter | .56 in |
Applications | Ind Facilities & Factories - Facility: Safety and Security Systems |
Height | .56 in |
Weight | .5 lb |
Standard | CE,CSA C22.2,UL |
Connection Type | Ferrule |
Family Brand Name | Bussmann Series |
Class | Class RK1 |
Tc Connection | Ferrule end x ferrul |
Amperage | 20 Amp |
Response Time | 8 seconds at 500% |
End Type | Ferrule |
Interrupt Rating | 100 kA |
Element | Dual |
Sub Brand | Bussmann Series |
Blade Dimensions | 2.0000 IN X 0.5600 I |
