Manufacturer | Allen Bradley / Rockwell |
---|---|
Mfg Catalog # | 1762-L40BXB |
Codale Part # | 1187805 |
UPC | 61259827931 |
Catalog Description | MicroLogix 1200, 24V dc power, (20) standard 24V dc and (4) fast 24V dc digital inputs, (8) relay outputs, (7) standard 24V dc FET outputs, (1) fast 24V dc FET output |
Codale Part No. | 1187805 |
Product Long Description | MicroLogix 1200, 24V dc power, (20) standard 24V dc and (4) fast 24V dc digital inputs, (8) relay outputs, (7) standard 24V dc FEToutputs, (1) fast 24V dc FET output |
Type | Controller |
Sub Brand | MicroLogix 1200 |
Mounting | DIN Rail, Panel Mount |
Width | 160 |
Enclosure Specification | IP20 |
Height | 90 |
Operating Temperature | 0... 55 °C (32...131 °F) |
Depth | 87 |
Display Type | No |
Power Supply | 24V DC |
Number of Channels | 24 I/P, 16 O/P |
Interface | RS-232C Port |
Input Signal | 24V DC |
Communication | DF1, DH-485, Modbus RTU, ASCII |
Memory | 6 KB |
Output Signal | (8) Relay and (8) 24V DC FET |
Product Short Description | 1762 MicroLogix 1200 System, MicroLogix 1200, 24V dc power, (20) standard 24V dc and (4) fast 24V dc digital inputs, (8) relay outputs, (7) standard 24V dc FET outputs, (1) fast 24V dc FET output |
Item Long Description | MicroLogix 1200 40 Point Controller |
MDM Pkg GTiN | 00612598279319 |
Width | 160 |
Operating Temperature | 0 To 55 C |
Type | 40-Point |
Mounting Type | DIN Rail, Panel Moun |
Depth | 87 |
Standard | C-Tick,C-UL-us CL1DI |
Family Brand Name | Allen Bradley |
Class | controller |
Number of Channels | 24 I/P, 16 O/P |
Output | 8 relay - 8x24V DC s |
Power Supply | 24V DC |
Memory | 6 KB |
Output Signal | (8) Relay and (8) 24 |
Enclosure | IP20 |
Sub Brand | MicroLogix 1200 |
Input Voltage | 24 V |
Output Voltage | 24 V |
Display Type | No Display |
