Thin wall heat shrink, .19" (4.8mm) diameter, white cross-linked polyolefin, 25 pc. package quantity.
$3.04/pc (1 ea)
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Panduit
Mfg Catalog # HSTT19-48-Q10
Codale Part # 49378
Thin wall heat shrink, .19" (4.8mm) diameter, white cross-linked polyolefin, 25 pc. package quantity.

Overview

UPC 07498390649
Product Description HEAT SHRINK THIN, .19(4.8MM) DIA, WHITE
Catalog Description Thin wall heat shrink, .19" (4.8mm) diameter, white cross-linked polyolefin, 25 pc. package quantity.
Codale Part No. 49378
Product Long Description DRY-SHRINK Thin Wall Heat Shrink, 0.187 Inch (4.8 mm) Diameter, 0.093 Inch (2.4 mm) Maximum Recovered Inside Diameter, 48 Inch Lengths, 25 pieces, White. For use in insulating, protecting, harnessing and identifying electrical and electronic components. Shrink Ratio is 2 to 1. Temperature Range is -67 degrees Fahrenheit to 275 degrees Fahrenheit (-55 degrees Celsius to 135 degrees Celsius). Voltage is 600 Volts. UL Recognized. CSA Certified. Military Specification AMS-DTL-23053/5 Class 1 (material performance only).
Application For Dry Locations
Material Flame retardant polyolefin cross-linked except clear
Color White
Shrink Ratio 2:1
Product Short Description Thin wall heat shrink, .19" (4.8mm) diameter, white cross-linked polyolefin, 25 pc. package quantity.
MDM Item Long Description DRY-SHRINK Thin Wall
MDM Pkg GTiN 00074983906499
Color White
Type Heat Shrink
Thickness 0.5 mm
Material Flame Retardant Poly
Shrink Ratio 2:1
Applications For Dry Locations
Country of Origin KR
Pkg Qty 25
Family Brand Name Panduit
Outside Diameter 4.8 mm
Overall Length 4 ft
Inside Diameter 2.4 mm
Sub Brand Dry-Shrink
