Manufacturer | Panduit |
---|---|
Mfg Catalog # | HSTT19-48-QC |
Codale Part # | 49377 |
UPC | 07498390661 |
Product Description | HEAT SHRINK THIN, .19(4.8MM) DIA, CLEAR |
Catalog Description | Thin wall heat shrink, .19" (4.8mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity. |
Codale Part No. | 49377 |
Product Long Description | DRY-SHRINK Thin Wall Heat Shrink, 0.187 Inch (4.8 mm) Diameter, 0.093 Inch (2.4 mm) Maximum Recovered Inside Diameter, 48 Inch Lengths, 25 pieces, Clear. For use in insulating, protecting, harnessing and identifying electrical and electronic components. Shrink Ratio is 2 to 1. Temperature Range is -67 degrees Fahrenheit to 275 degrees Fahrenheit (-55 degrees Celsius to 135 degrees Celsius). Voltage is 600 Volts. Military Specification AMS-DTL-23053/5 Class 2 (material performance only). |
Application | For Dry Locations |
Material | Polyolefin cross-linked |
Color | Clear |
Shrink Ratio | 2:1 |
Product Short Description | Thin wall heat shrink, .19" (4.8mm) diameter, clear cross-linked polyolefin, 25 pc. package quantity. |
Item Long Description | DRY-SHRINK Thin Wall Heat Shrink, 0.187 Inch (4.8 mm) Diameter, 0.093 Inch (2.4 mm) Maximum Recovered Inside Diameter, 48 Inch Lengths, 25 pieces, Clear. For use in insulating, protecting, harnessing and identifying electrical and electronic components. Shrink Ratio is 2 to 1. Temperature Range is -67 degrees Fahrenheit to 275 degrees Fahrenheit (-55 degrees Celsius to 135 degrees Celsius). Voltage is 600 Volts. Military Specification AMS-DTL-23053/5 Class 2 (material performance only). |
MDM Pkg GTiN | 00074983906611 |
Color | Clear |
Type | Heat Shrink |
Thickness | 0.5 mm |
Material | Polyolefin Cross-lin |
Shrink Ratio | 2:1 |
Applications | For Dry Locations |
Country of Origin | KR |
Pkg Qty | 25 |
Family Brand Name | Panduit |
Outside Diameter | 4.8 mm |
Overall Length | 4 ft |
Inside Diameter | 2.4 mm |
Sub Brand | Dry-Shrink |
UNSPSC | 39121723 |
