Allen Bradley 140-CMN-4000 IEC Manual Starter
Product image thumbnail 0
Product image thumbnail 1
Product image thumbnail 2
$710.00/ea
Usually ships within 8 to 12 Days
ea
Adding...
Already a Customer? Log in to view your pricing
Manufacturer Allen Bradley / Rockwell
Mfg Catalog # 140-CMN-4000
Codale Part # 124345

Features

  • Offers external rotary operators
  • Provides overload protection, Trip Class 10
  • Includes visible trip indication

Documentation

Circuit Breaker Photo

System Voltage Data

  • Supply Voltage: 480V 60Hz

Circuit Breaker

  • UL Listed Application Ratings: UL 508 - Manual Motor Controller
  • Adj. Thermal Current Range (A): 25.0 - 40.0
  • Application: Normal Motor
  • Circuit Breaker Type: Motor Protection Circuit Breaker

Factory Options

  • Factory Modifications, Trip Indicating Auxiliary Contacts - Top Front Mounting: None
  • Factory Modifications, Auxiliary Contacts - Bottom Front Mounting: None
  • Factory Modifications, UV and Shunt Trips -Top Front Mounting: None

Short Circuit Coordination

  • Short Circuit Coordination: Type 1

Certifications and Approvals

  • Manual, Self-Protected Combination Motor Controller
  • Manual Motor Controller with Optional Approvals: Group Installation, Motor Disconnect, Tap Conductor Protection
  • For UL Certifications Directory: http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm
  • CE: Marking is self-certified
  • EN60947-4: Overload Protection
  • EN60947-2: Circuit Breaker
  • UL508: and CSA 22.2, No. 14

Overview

Codale Part No. 124345
Product Long Description Our Bulletin 140-CMN Motor Protection Circuit Breakers are UL Listed/CSA Certified as Manual Motor Controllers (with approvals for At-Motor Disconnect and Group Installation). These devices are rated from 16...90 A. In NEC/CEC Group Installations, they must be applied per the appropriate rules, which require the use of an upstream branch circuit, short-circuit protective device.
Application Normal Motor
Supply Voltage 480V 60Hz
Circuit Breaker Type Motor Protection Circuit Breaker
Product UPC 66207261425
Voltage 480 Volt
Type Magnetic
Family Brand Name Allen Bradley
Circuit Breaker Type Motor Protection Circuit Breaker
Power Rating 11 kW at 230 V, 13 kW at 400 V
Blade Dimensions 79.5 mm W x 140.6 mm D x 168 mm H
Trip Class Class 10
