Hubbell HBL2813SW 30 Amp 120/208 VAC 4-Pole 5-Wire NEMA L21-30R Gray Watertight Locking Connector Body

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL2813SW | Codale Part # 104704
$619.15/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Twist-Lock®, Watertight Safety-Shroud®, Female Connector Body, 30A 3-Phase Wye 120/208V AC, 4- Pole 5-Wire Grounding, NEMA L21-30 R, Screw Terminal, Black PBT housing, White PBT clamps.

Technical Information

Amperage
30 Amp
Applications
For Heavy Duty Industrial
Conductor Size
12-8 AWG
Connection Type
Pressure Screw Terminal
Current
30 Amp
Material
Composite
NEMA
L21-30R
Number of Conductors
5
Number of Phases
3 Phase
Number of Poles
4-4 Pole
Number of Ports
4
Number of Wires
5 Wire
Operating Temperature
-40 degrees C
Size
Standard
Tc Connection
Pressure Screw Terminal
Temperature Rating
-40 to 75 degrees C/-25 to 75 degrees C
Type
Standard, Grounding, Shrouded Watertight
Voltage
120/208 Volt
Wire Count
5
Wire Size
16-8 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585232102
Color
Black/White
Environmental Conditions
Watertight
Product UPC
78358523210
Weight
0.65 lb

Dimensions

Height
4.4 Inch
Length
2-3/4 Inch
Width
2.75 in

Certifications and Compliance

Country of Origin
USA
Features
  • UL Type 4X Environmental seal protects connection while in use.
  • One-piece, engineered thermoplastic housing is impact-resistant for heavy-duty industrial environments
  • Closure cap is included for environmental seal when device is not in use
  • Superior cord grip design protects terminations from excess strain.
  • Shrouded Watertight Construction
