Product image for Hubbell HBL11 3/4 Hp 10 Amp 250 VAC SPST Panel Mount Screw Terminal Bat Handle Heavy Duty Switch
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Image thumbnail 4
Email

Hubbell HBL11 3/4 Hp 10 Amp 250 VAC SPST Panel Mount Screw Terminal Bat Handle Heavy Duty Switch

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL11 | Codale Part # 111152
$8.89/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Switches and Lighting Controls, Commercial Grade, Panel Mount and Specialty Switches, Bat Handle Switches, Single Pole Single Throw, 10A 250V/10A 125V, Terminal Screws,

Technical Information

Actuator
Bat Handle
Amperage
20 Amp
Applications
On/Off
Contact Configuration
SPST
Contact Rating
As Indicated
Current
10 Amp
Horsepower
0.75 hp
Indicator
Comes with Indicator Plate
Interrupt Rating
10, 20 AIC
Material
Thermoplastic
Number of Poles
1-1 Pole
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
UL
Style
Screw Terminal
Switch Type
Single Pole
Tc Connection
Screw Terminal
Type
Bat Handle
Voltage
250/125 Volt
Wattage
2500 Watt

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Panel Mount Switches

General Product Info

12-Digit UPC
783585016672
Color
Brass
Product Series
Single Pole/Single Throw
Product UPC
78358501667
Weight
0.05 lb

Dimensions

Height
1.13 Inch
Length
2.2 Inch
Width
0.56 in

Certifications and Compliance

Country of Origin
China
Features
  • Nickel Plated for Corrosion Resistance
