Product image for Burndy YGF292N Compression Grounding Plate; Copper; 2-Hole; Accommodates: #2 AWG - 250 kcmil; 1/2" Stud; 1-3/4" Stud Hole Spacing
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Email

Burndy YGF292N Compression Grounding Plate; Copper; 2-Hole; Accommodates: #2 AWG - 250 kcmil; 1/2" Stud; 1-3/4" Stud Hole Spacing

Manufacturer: Hubbell-Burndy | Catalog # YGF292N | Codale Part # 125018
$217.89/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet
Copper Compression Grounding Plate, 2 AWG - 250 kcmil, 1/2" Stud, 1-3/4" Stud Hole Spacing.

Technical Information

Applications
Used to Position the Grounding Plate on a Threaded Rod Prior to Placement of the Concrete
Conductor Size
1 AWG
Conductor Type
CU C Str-Size
Material
Copper
Mounting Type
(2) 1-3/4 in Hole
Plated?
No
Plating Type
Unplated
Standard
ANSI C-73
Type
YGF
Wire Size
2 AWG-250 kcmil

Manufacturer Information

Brand
Burndy
Sub Brand
Grounding and Bonding

General Product Info

12-Digit UPC
781810220504
Product UPC
78181022050
Weight
1.8100 lb

Dimensions

Height
3.62 Inch
Length
5.78 Inch
Overall Length
147 mm
Width
2.00 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
Yes
Features
  • Compression Grounding Plate designed for the rigors of concrete construction
  • Made of high strength, high-conductivity cast copper alloy body
  • Plate comes with a tapped hole on the underside for ease of positioning prior to pouring concrete
  • UL467 Listed, Acceptable for direct burial in earth or concrete
  • Prefilled with oxide inhibiting compound and strip sealed
