Burndy MY293 Dieless Crimper, #8 Str-250 kcmil CU Code, #8 Str-4/0 Str AL Code, 30-250 Navy CU Navy Cable

Manufacturer: Hubbell-Burndy | Catalog # MY293 | Codale Part # 1451822
$2,094.78/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet
Dieless Hytool, 22.65 in Length ,#8 str.-250 kcmil.

Technical Information

Applications
TOOL CONNECTORS MY29-3, MY29-3C Copper-YA, YA-L, YS-L, MY29-3CF Aluminum-YA-A, YS-A, MY29-11 Copper-YA, YA-L, YS, MY29-11C YAV-FX,YS-L, YAV-L, YSV-L, MY28 YAV-L, YSV-L, MY28-4 YAV-A-L, YSV-A-L, YAV-A-R, MY28-6 YAE-L, YAEV-RS, YAEV-H, YAEV-RH
Conductor Size
8 AWG-250 kcmil
Material
Steel
Type
Dieless
Wire Size
8 AWG-250 kcmil

Manufacturer Information

Brand
Burndy
Sub Brand
Hytool

General Product Info

12-Digit UPC
781810462003
Finish
Matte Black
Housing Material
Forged Steel
Product UPC
78181046200
Used With
MY29-3, MY29-3C Copper-YA, YA-L, YS-L, MY29-3CF Aluminum-YA-A, YS-A, MY29-11 Copper-YA, YA-L, YS, MY29-11C YAV-FX, YS-L, YAV-L, YSV-L, MY28 YAV-L, YSV-L, MY28-4 YAV-A-L, YSV-A-L, YAV-A-R, MY28-6 YAE-L, YAEV-RS, YAEV-H, YAEV-RH Tool Connectors
Weight
8 lb

Dimensions

Height
1.12 Inch
Length
22.65 Inch
Overall Length
22.65 in
Width
4.86 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
No
Features
  • Two-ply covered handles on MY29-3C and MY29-11C designs
  • Heavy duty forged steel back, body and handles
  • Strong reinforced forged steel back
  • .31\" dia. hole for bench mounting operations
  • Comfort grips
  • Extra strong, heavy reinforced handles
  • Indentor die
  • Knurled steel adjusting knob
  • No Separate Dies Required, Fast And Easy Tool Setting For The Connector/ Conductor Combination Simply By Aligning The White Scribe On The Nest Die With The Wire Size On The Gauge For Proper Crimping Results, Easy To Adjust Nest Die With Knurled Steel Knob And Machine Threads, Fast, Medium And High Volume Crimping Is Easily Accomplished By Bench Mounting The Type MY Tool In The BMY-BCH-MT Bench Mount Adapter, High Quality Rugged Tool Design Manufactured From Heavy Duty Forged Steel With Strong Reinforced Back And Handles, Compression Terminals And Splices Are UL Listed And CSA Certified When Installed With Type MY HYTOOL
