Milwaukee 48-20-5135 SDS-Max and Spline Thick Wall Carbide Tipped Core Bit 2"

Manufacturer: Milwaukee Tool | Catalog # 48-20-5135 | Codale Part # 1483672
$156.93/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Milwaukee®'s SDS-Max and spline thick wall core bits are used for drilling large through holes into brick, block, concrete. Includes core bit, guide plate, and centering pin.

Technical Information

Applications
For Drilling Large Holes
Bit Type
Percussion
Cutting Depth
4-1/16 in
Drilling Depth
4.062 in
Material
Carbide
Shank Size
12/18 in L
Shank Type
Spline Drive, SDS Max
Size
2 in
Style
Thick Wall For SDS-MAX Or Spline
Type
Thick Wall

Manufacturer Information

Brand
Milwaukee Tool
Sub Brand
MILWAUKEE

General Product Info

12-Digit UPC
045242105953
Product UPC
04524210595
Used With
Thick Wall Core Bit Shank 48-03-3564 (12 in) or 48-03-3565 (18 in), 7-1/2 in Extension
Weight
2.3200 lb

Dimensions

Depth
4-1/16 Inch
Diameter
2 Inch
Length
4-3/8 Inch
Shank Diameter
0.0 in
Features
  • Thick wall design
  • 2 in. diameter
  • Usable cutting depth 4-1/16 in.
  • Use with 12 in. or 18 in. spline adapter shanks (48-03-3564, 48-03-3565) and 12 in. or 18 in. SDS-Max adapter shanks (48-03-3572, 48-03-3573)
  • Use with 7-1/2 in. extension 48-95-6085
  • Use with guide plate 48-20-5170 and centering pin 48-20-5199
  • Includes core body with guide plate & centering pin
