Ilsco ACO-600 Aluminum Compression Pigtail Adaptor Offset, Conductor Size 600, Tin Plated, UL, CSA

Manufacturer: Ilsco | Catalog # ACO-600 | Codale Part # 1551524
$88.89/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
ILSCO Aluminum Offset Pigtail Adaptor, Compression connection, Dual Rated, Aluminum material, Tin plated connector,Standard barrel, UL 486A/B Listed, C22.2 No. 65-03, 180. connecting angle, Copper/Aluminum Primary Conductor 600 kcmil, Contains DE-OX®, 1 conductors, no sight window, Supplied with insulating cover insulation, rated for 600 V, die color code Yellow, primary color Silver, die index 18,

Technical Information

Applications
For Terminating Connector
Barrel Length
2.03 in
Barrel Type
Standard
Color Coding
Yellow
Conductor Material
Aluminum,Copper
Conductor Size
600 kcmil
Conductor Type
Stranded
Connection Type
Compression
Contact Material
Aluminum
Material
Aluminum
Number of Conductors
1
Pin Length
1.640 in
Size
L:4.885;W:1.64;H:1.64 IN
Standard
UL File Number: E62525,UL Specifications: UL 486A-B,CSA File Number: LR-29601
Temperature Rating
90 degrees C
Type
Offset, Round, Long Sleeve, Dual-Rated
Voltage
600 Volt

Manufacturer Information

Brand
Ilsco
Sub Brand
ClearChoice

General Product Info

12-Digit UPC
783669009620
Color
Yellow
Product UPC
78366900962
Weight
0.402 lb

Dimensions

Height
1.64 Inch
Inside Diameter
0.923 in
Length
4.885 Inch
Outside Diameter
1.453 in
Width
1.64 in
