Thomas & Betts D71 8 AWG Wire Range 1/4 Inch Bolt Hole Non-Insulated Brazed Seam Ring Terminal

Manufacturer: ABB Thomas & Betts | Catalog # D71 | Codale Part # 1568956
$179.95/c (100 ea)
ea
Order in multiples of 200 (pack qty)
Log in or register to view your price, purchase history, and more!
400 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet Product Catalog Page
Non-Insulated Large Brazed Seam Ring Terminal, Length 1.13 Inches, Width .48 Inches, Bolt Hole 1/4 Inch, Wire Range #8 AWG, Copper, Tin Plated, 200 Pack

Technical Information

Barrel Type
Brazed Seam
Conductor Size
8 AWG
Insulation Type
Non-Insulated - Brazed Seam
Material
Copper
Standard
UL E9809
Stud Size
1/4 in
Temperature Rating
150 degrees C
Type
Short Sleeve
Voltage
600 Volt
Wire Size
8 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210811529
Color
Metallic
Finish
Electro Tin Plated
Product UPC
78621081152
Features
  • These non-insulated ring terminals are made of electrolytic copper for high conductivity. They can be installed with crimping tools having a single indentor or double indentor (recommended for solid wire). Serrated barrel increases grip on wire.
Notes
  • Not available on Mylar Tape.
