Product image for Allen-Bradley 100-D630ED11 630 Amp IEC MCS D Contactor
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Image thumbnail 3
Email

Allen-Bradley 100-D630ED11 630 Amp IEC MCS D Contactor

Manufacturer: Allen Bradley / Rockwell | Catalog # 100-D630ED11 | Codale Part # 2291473
$10,774.07/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
IEC 630 A MCS D Contactor

Technical Information

Amperage
630 Amp
Coil Voltage
110 - 130 VAC at 50/60 Hz, 110 - 130 VDC
Conductor Size
2/0 AWG-500 kcmil
Contact Configuration
1 NO - 1 NC Auxiliary
Current
630 Amp
Mounting Type
Panel
Number of Phases
3 Phase
Number of Poles
3 Pole
Power Rating
200 kW at 230 V, 355 kW at 400 V, 415 V, 500 kW at 500 V, 690 V
Standard
C-TICK,CCC,CE,CUL,KC,MARINE,UL
Temperature Rating
-25 to 60 degrees C
Type
MCS D, Non-Reversing
Voltage
230-1000 VAC, 24-440 VDC

Manufacturer Information

Brand
Allen-Bradley
Sub Brand
IEC

General Product Info

12-Digit UPC
781180181597
Environmental Conditions
-40 to 80 deg C Storage Temperature, IEC 60068-2-30 Climatic Withstand, 2000 NN m, per IEC60947-4 Maximum Altitude of Installation Site
Product UPC
78118018159
Weight
88.0000 lb
Features
  • Meets IEC, UL, and CSA standards requirements
  • RoHs compliant
  • Simplifies selection with electronic wide-range AC/DC coils
  • Includes reversible coil terminations (line or load side)
  • Provides reversible coil terminations (line or load side)
  • Saves energy with low power consumption
  • Provides front and side mounting of auxiliary contacts
  • Offers common accessories for all contactor sizes
  • Includes built-in surge suppression
  • Includes electronic and pneumatic timing modules
  • Reduces drop-out time to 18-23ms, a reduction of up to 50% compared to standard electronic coils
  • Provides IP2X finger protection
  • Available integrated PLC interface
  • Complies with RoHs
  • Includes built-in surge suppression
  • Meets IEC, UL, and CSA standards requirements
  • Includes space-saving coil-mounted control modules
