Mersen ATQ20 Time-Delay Amp-Trap ATQ Midget Fuse - 20amp. Rated 500 volts AC

Manufacturer: Mersen | Catalog # ATQ20 | Codale Part # 2370321
$40.31/ea
ea
Log in or register to view your price, purchase history, and more!
14 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
Amp-Trap ATQ midget time-delay fuses are rated 500VAC with 42 ampere ratings from 1/10 to 30A. They are an excellent choice for supplemental protection of circuits where the available short circuit current does not exceed 10,000A. (Not for Branch Circuit Protection)

Technical Information

Amperage
20 Amp
Applications
For Supplemental Protection of Lighting, Solenoid, Motor and Transformer Circuits up to 500 VAC
Fuse Class
Midget
Insulation Material
GMG
Interrupt Rating
10 kAIC
Mounting Type
Clip
Rated Voltage AC
500 V
Tc Connection
Ferrule
Terminal Material
Tin-Plated Copper
Terminal Type
Ferrule
Type
Time-Delay
Voltage
500 VAC

Packaging

Pkg Qty
10

Manufacturer Information

Brand
Ferraz Shawmut Canada, Inc.

General Product Info

12-Digit UPC
782001904616
Class
M
Product UPC
78200190461
Used With
UltraSafe Fuseholders
Weight
0.012 lb

Dimensions

Diameter
0.41 Inch
Length
1-1/2 Inch
Features
  • Numerous ratings for a wide variety of applications up to 500VAC
  • Time-delay (12 seconds at 200 percent rating) for circuits with high inrush current
  • Can be used with UltraSafe™ Fuse holders
  • 1 1/2\" x 13/32\" (10 mm x 38 mm) dimensions
Applications
  • Supplemental protection of lighting, solenoid, motor and transformer circuits
Approvals & Standards
  • UL listed to standard 248-14 File E33925
  • CSA Certified to Standard C22.2 No. 248.14
