3M 7100022418 3M™ Heat Shrink Thin-

Manufacturer: 3M | Catalog # 7100022418 | Codale Part # 2448190
$1.45/ea
ea
Order in multiples of 100 (pack qty)
Log in or register to view your price, purchase history, and more!
300 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet
3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Technical Information

Applications
For a Wide Variety of Industrial and Military Applications
Dielectric Strength
900 V/mil
Material
Polyolefin
Max Operating Temperature
135.0 degrees C
Operating Temperature
-55 degrees C
Shrink Ratio
2:1
Standard
ANATEL,CA Energy Commission Title 24,COFETEL,CUL,FCC,IC,SUTEL
Temperature Rating
-67 to 275 degrees C
Tensile Strength
2400 lb/in
Type
Flexible

Manufacturer Information

Brand
3M

General Product Info

12-Digit UPC
051135355749
Color
Black
Product UPC
05113535574
Weight
0.9000 lb

Dimensions

Inside Diameter
0.125
Length
100 Foot
Outside Diameter
0.25 in
Overall Length
100.0 ft
Thickness
0.025

Certifications and Compliance

Country of Origin
USA
Features
  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
