Hubbell HBL5279-C 15A 125V INSULGRIP White Nylon Flanged Receptacle

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL5279C | Codale Part # 24712
$99.19/ea
ea
Log in or register to view your price, purchase history, and more!
20 available

For Delivery

Not in local stock *
Check your local branch
Primary Spec Sheet Product Catalog Page
Straight Blade Devices, Inlets, Flanged, Commercial/Industrial Grade, 2-Pole 3-Wire Grounding, 15A 125V, 5-15R, White, Single Pack.

Technical Information

Amperage
15 Amp
Applications
Heavy duty, high leverage diagonal cutter
Conductor Size
14-12 AWG
Current
15 Amp
Dielectric Strength
Withstands 2,000V minimum
Horsepower
0.50 hp
Material
Thermoplastic
Mounting Type
Screw
NEMA
5-15R
Number of Phases
1 Phase
Number of Poles
2 Pole
Number of Wires
3 Wire Grounding
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
C22.2,CSA,File E2186,NEMA® WD-6,No. 42,UL
Style
Finder Groove Face
Tc Connection
Screw, 6 Terminals
Type
Single, Standard, Heavy Duty
Voltage
125 Volt
Wattage
1875 Watt
Wire Count
3
Wire Size
18-10

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
783585173603
Color
White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product Series
Insulgrip
Product UPC
78358517360
Weight
0.15 lb

Dimensions

Height
1.71 Inch
Length
1.71 Inch
Width
1.69 in

Certifications and Compliance

Country of Origin
USA
Features
  • Impact resistant thermoplastic construction
  • Backwired terminations for ease of installation
  • #8-32 Multiple drive terminal screws
  • Mounting screws included
