Hubbell HBL9333 30 Amp 125/250 Volt 3-Pole 3-Wire NEMA 10-30P Black/White Nylon Straight Blade Plug

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL9333 | Codale Part # 24714
$207.50/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Male Plug, Nylon, 4-Position, Heavy Duty, Industrial/Commercial Grade, Angled, 2-Pole 3-Wire Grounding, 30A 125/250V, 10-30P, Black, Single Pack.

Technical Information

Amperage
30 Amp
Applications
Industrial and Commercial
Conductor Size
12-4 AWG
Cord Type
Portable
Current
30 Amp
Material
Nylon
Mounting Type
Cord
NEMA
10-30P
Number of Poles
3 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
C22.2 No. 42 File 280,CSA,UL,UL498 File E1706
Tc Connection
Terminal Screws
Type
Standard Sized, Angled, 4-Position
Voltage
125 Volt
Wattage
7.5 kW
Wire Count
3
Wire Size
12-4 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Insulgrip®

General Product Info

12-Digit UPC
783585015422
Color
Black
Environmental Conditions
Indoor Dry unless protected by additional means
Product UPC
78358501542
Weight
0.55 lb

Dimensions

Height
1.88 Inch
Length
4.33 Inch
Width
2.75 in

Certifications and Compliance

Country of Origin
USA
Performance
  • Electrical - Current Interrupting - Certified for current interrupting at full rated current
  • Electrical - Dielectric Voltage - Withstands 2,000V minimum
  • Environmental - Flammability - UL 94 V-2
  • Environmental - IP Suitability - IP20
  • Environmental - Operating Temperatures - Maximum continuous 75°C, minimum -40°C (w/o impact)
  • Mechanical - Product Identification - Ratings are a permanent part of the device
  • Mechanical - Terminal Accommodation - #12-#4 AWG copper stranded or solid conductor only
  • Mechanical - Terminal Identification - Terminals identified in accordance with UL 498 and CSA
Voltage Rating
  • 125 V
  • 250 V
