Hubbell HBL26519 60A 600V HUBBELLOCK Blue Thermoplastic / Steel Plug

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL26519 | Codale Part # 27004
$2,464.22/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Locking Devices, Hubbellock®, Industrial, Male Plug, 60A 600V AC, 4-Pole 5-Wire Grounding Hubbellock® Plug, Black phenolic interior with Blue thermoplastic sleeve and steel housing, Non NEMA, Screw Terminal

Technical Information

Amperage
60 Amp
Applications
Heavy Duty Industrial
Conductor Size
10-4 AWG
Cord Type
Portable
Current
60 Amp
Material
Nylon
Mounting Type
Cord
Number of Poles
4 Pole
Number of Wires
5 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA Standard,UL Standard
Tc Connection
Pressure Terminal Screws
Type
Male, Industrial Grade
Voltage
600 Volt
Wire Count
5
Wire Size
8-4 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Hubbell-Lock®

General Product Info

12-Digit UPC
783585017334
Color
Blue
Environmental Conditions
Indoor Dry unless protected by additional means
Product UPC
78358501733
Weight
2.1 lb

Dimensions

Height
5.9 Inch
Length
3.03 Inch
Width
3.03 in

Certifications and Compliance

Country of Origin
USA
Features
  • Molded-in male contacts are resistant to damage and provide a consistently positive connection
  • Insulated, color coded metallic housing enhances safety and abuse resistance
  • Box terminals in conjunction with stainless steel terminal screws provide maximum termination strength and dependability
