Hubbell HBL9758VY 20 Amp 250 Volt 2-Pole 2-Wire NEMA 2-20P Yellow Nylon Straight Blade Plug

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL9758VY | Codale Part # 27778
$78.64/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Straight Blade Devices, Male Plug, Nylon, Valise Series, Commercial Grade, Straight, 2-Pole 2-Wire Non Grounding, 250V, 20A 2-20P, Yellow, Single Pack.

Technical Information

Amperage
20 Amp
Applications
Industrial/Commercial
Conductor Size
16-10 AWG
Cord Type
All Portable
Current
20 Amp
Material
Nylon
NEMA Size
2-20P
Number of Poles
2 Pole
Number of Wires
2 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Tc Connection
Terminal Screws
Type
Valise
Voltage
2,000 Volt
Wattage
2000 Watt
Wire Count
2
Wire Size
18-14 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade Devices

General Product Info

12-Digit UPC
783585013312
Color
Yellow
Environmental Conditions
Indoor Dry unless protected by additional means
Product UPC
78358501331
Weight
0.1300 lb
Listings
  • UL Listed to UL498 File E1706
  • CSA Certified to C22.2 No. 42 File 280C
  • NEMA® WD-6 Compliant
Features
  • Hinged one piece body design for easy assembly
  • Powerful cord grips prevent conductor slippage and strain
