Product image for Hubbell IG5461 20 Amp 250 Volt 2-Pole 3-Wire NEMA 6-20R Orange Isolated Ground Single Straight Blade Receptacle
Image thumbnail 0
Image thumbnail 1
Image thumbnail 2
Email

Hubbell IG5461 20 Amp 250 Volt 2-Pole 3-Wire NEMA 6-20R Orange Isolated Ground Single Straight Blade Receptacle

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # IG5461 | Codale Part # 28120
$61.40/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Receptacles, Single, Specification Grade, 2-Pole 3-Wire Grounding, 20A 250V, 6-20R, Orange, Single Pack

Technical Information

Amperage
20 Amp
Applications
Extra Heavy Duty
Base Material
PBT
Conductor Size
14-10 AWG
Current
20 Amp
Dielectric Strength
Withstands 2,000V minimum
Face Material
Nylon
Horsepower
2 hp
Material
Nylon
NEMA
6-20R
Number of Phases
1 Phase
Number of Poles
2-2 Pole
Number of Wires
3,3
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA 22.2,Guide RTRT Fed Spec WC596G,NEMA® WD-6,No. 42 File 285,UL,UL498 File No. E2186
Style
Finder Groove Face
Tc Connection
Back and Side Wired Terminal Screws
Type
Single
Voltage
250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Straight Blade

General Product Info

12-Digit UPC
783585880501
Color
Orange
Environmental Conditions
Indoor Dry Unless Protected By Additional Means
Product Series
Hubbell-PRO
Product UPC
78358588050
Weight
0.2 lb

Dimensions

Height
1.19 Inch
Length
3.28 Inch
Width
1.62 in

Certifications and Compliance

Country of Origin
USA
Features
  • Triangle marking on face indicates isolated ground
  • Patented bypass contact design
  • Isolated Ground
