Hubbell HBL5466CA 20 Amp 250 Volt 2-Pole 3-Wire NEMA 6-20P Black/White Nylon Straight Blade Angle Plug

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL5466CA | Codale Part # 29217
$57.81/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Straight Blade Devices, Male Plug, Insulgrip Heavy Duty, Industrial/Commercial Grade, Straight, 2-Pole 3- Wire Grounding, 20A 250V, 6-20P, Black and White, Single Pack.

Technical Information

Amperage
20 Amp
Applications
Commercial, Industrial
Conductor Size
18-10 AWG
Cord Type
Portable
Current
20 Amp
Horsepower
2 hp
Material
Thermoplastic
NEMA
6-20P
Number of Poles
2 Pole
Number of Wires
3 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized
Standard
CSA,E2186,UL
Style
Angled
Tc Connection
Spade, 2 Terminals
Type
Standard Sized
Voltage
250 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
18-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade and Twist-Lock

General Product Info

12-Digit UPC
783585174754
Color
Black,White
Environmental Conditions
Indoor Only
Product Series
Insulgrip
Product UPC
78358517475
Weight
0.15 lb

Dimensions

Height
1.22 Inch
Length
2.11 Inch
Width
1.53 in

Certifications and Compliance

Country of Origin
USA
Features
  • 8-Position angled plug
  • Low profile
  • Roomy wiring chamber provides ample space for wiring
