Ilsco ACO-250 Aluminum Compression Pigtail Adaptor Offset, Conductor Size 250, Tin Plated, UL, CSA

Manufacturer: Ilsco | Catalog # ACO-250 | Codale Part # 310296
$43.41/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
ILSCO Aluminum Offset Pigtail Adaptor, Compression connection, Dual Rated, Aluminum material, Tin plated connector,Standard barrel, UL 486A/B Listed, C22.2 No. 65-03, 180. connecting angle, Copper/Aluminum Primary Conductor 250 kcmil, Contains DE-OX®, 1 conductors, no sight window, Supplied with insulating cover insulation, rated for 600 V, die color code Brown, primary color Silver, die index 14,

Technical Information

Applications
For Terminating Connector
Barrel Length
1.41 in
Barrel Type
Standard
Color Coding
Brown
Conductor Material
Aluminum,Copper
Conductor Size
250 kcmil
Conductor Type
Stranded
Connection Type
Compression
Contact Material
Aluminum
Material
Aluminum
Number of Conductors
1
Pin Length
1.220 in
Size
L:3.715;W:1.1;H:1.29 IN
Standard
CSA File Number: LR-29601,UL Specifications: UL 486A-B,UL File Number: E62525
Temperature Rating
90 degrees C
Type
Long, Round, Offset
Voltage
600 Volt

Packaging

Pkg Qty
10

Manufacturer Information

Brand
Ilsco
Sub Brand
ClearChoice

General Product Info

12-Digit UPC
783669009569
Color
Brown
Product UPC
78366900956
Weight
0.166 lb

Dimensions

Height
1.29 Inch
Inside Diameter
0.59 in
Length
3.715 Inch
Outside Diameter
1.29 in
Width
1.1 in
