Hubbell HBL9977C 20 Amp 125/250 Volt 3-Pole 3-Wire NEMA 10-20P Black Nylon Straight Blade Plug

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL9977C | Codale Part # 314544
$110.64/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Straight Blade Devices, Male Plug, Nylon, Heavy Duty, Industrial/Commercial Grade, Straight, 3-Pole 3-Wire Non Grounding, 20A 125/250V, 10-20P, Black and White, Single Pack.

Technical Information

Amperage
20 Amp
Applications
Industrial/Commercial
Conductor Size
14-10 AWG
Cord Type
All Portable
Current
20 Amp
Grounding
Non-Grounding
Material
Composite
Mounting Type
Cord
NEMA
10-20P
Number of Poles
3 Pole
Number of Wires
3 Wire
Size
Standard Sized
Tc Connection
Terminal Screws
Type
Insulgrip
Voltage
2,000 Volt
Wattage
5000 Watt
Wire Count
3
Wire Size
14-10 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Straight Blade Devices

General Product Info

12-Digit UPC
783585013121
Color
Black,White
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product UPC
78358501312
Weight
0.0087 lb
Features
  • Ribbed nylon housing is impact and chemical resistant
  • Fast lead assembly screws
  • Beveled housing prevents snagging
Listings
  • UL Listed to UL498 File E1706
  • CSA Certified to C22.2 No. 42 File 280
  • NEMA® WD-6 Compliant
