Hubbell HBL6375S REP Locking INLET, SPIDER 50A

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # HBL6375S | Codale Part # 3218519
$648.43/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Temporary Power Products, Spider Portable Power, Replacement Parts, Flanged Inlet, 50A 125/250V

Technical Information

Amperage
50 Amp
Applications
Heavy Duty Industrial
Conductor Size
10-6 AWG
Current
50 Amp
Dielectric Strength
Withstands 2,000V minimum
Grounding
Grounding
Material
Composite
Mounting Type
Screw
Number of Phases
1 Phase
Number of Poles
3 Pole
Number of Wires
4 Wire
Operating Temperature
-40 degrees C
Size
Standard Sized Product
Standard
CSA C22.2 No.42,UL 498
Style
Inlet
Tc Connection
Terminal Screws
Type
Flanged, Single Male, Straight, Industrial Grade
Voltage
125/250 Volt
Wattage
12500 Watt
Wire Count
4
Wire Size
10-6 AWG

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Twist-Lock®

General Product Info

12-Digit UPC
783585369594
Color
Black
Environmental Conditions
Indoor Dry Unless Protected by Additional Means
Product UPC
78358536959
Weight
0.80 lb

Dimensions

Height
3-3/4 Inch
Length
3.8 Inch
Width
3.43 in

Certifications and Compliance

Country of Origin
USA
Features
  • Metallic flanged casing provides maximum strength and protection
  • Thermoset interior provides superior heat resistance
  • Spider Box Replacement
