Siemens DTNF361R 600 VAC/250 VDC 30 Amp 3-Pole 3-Wire NEMA 3R Heavy Duty Non-Fusible Safety Switch

Manufacturer: Siemens | Catalog # DTNF361R | Codale Part # 3253004
$1,399.87/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet
Siemens Low Voltage Circuit Protection Heavy Duty Safety Switches. Type: ENCLOSED, SAFETY SWITCH Std: UL V. Rating: 600V A. Rating: 30A Wattage: 3W No. Of Poles: 3P F. Rating: 60Hz Action: DOUBLE THROW Material: 304SS Enclosure: TYPE 3R. 2-3 point mounting holes. O. Cycles: 10000 O. Temperature: (-20F-120F) AMBIENT TEMPERATURE Environmental Conditions: OUTDOOR

Technical Information

Action
DOUBLE THROW
Actuator
DOUBLETHROW
Ambient Temperature
-29 C
Amperage
30 Amp
Applications
LOADTRANSFERBETWEENPOWERSOURCES
Connection Type
MECHANICAL LUGS
Enclosure
NEMA3R
Frequency
60 Hz
Insulated?
No
Material
Steel
Mounting Type
SURFACE
Number of Poles
3 Pole
Operating Cycles
10000
Operating Temperature
-29 degrees C
Tc Connection
MECHANICALLUGS
Type
DOUBLETHROWSWITCH
Voltage
600 Volt
Wattage
3 Watt

Manufacturer Information

Brand
Siemens
Sub Brand
VBII

General Product Info

12-Digit UPC
783643454231
Product UPC
78364345423
Weight
45.000 lb

Dimensions

Height
25 Inch
Length
10 Inch
Width
12.000 in

Certifications and Compliance

Country of Origin
Mexico
