Thomas & Betts D26 Ring Tongue Terminal

Manufacturer: ABB Thomas & Betts | Catalog # D26 | Codale Part # 3272223
$163.95/c (100 ea)
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page
Non-Insulated Large Brazed Seam Ring Terminal, Length 1.13 Inches, Width .48 Inches, Bolt Hole #10, Wire Range #8 AWG, Copper, Tin Plated, 200 Pack

Technical Information

Conductor Size
8 AWG
Insulation Type
Non-Insulated - Brazed Seam
Material
Copper
Standard
UL E9809
Temperature Rating
150 degrees C
Type
Non-Insulated Ring Terminal
Voltage
600 Volt
Wire Size
8 AWG

Manufacturer Information

Brand
ABB
Sub Brand
Sta-Kon®

General Product Info

12-Digit UPC
786210811475
Color
Metallic
Finish
Electro Tin Plated
Product UPC
78621081147
Weight
0.0113 lb
Features
  • These non-insulated ring terminals are made of electrolytic copper for high conductivity. They can be installed with crimping tools having a single indentor or double indentor (recommended for solid wire). Serrated barrel increases grip on wire.
Notes
  • Not available on Mylar Tape.
