HWDK PG2 REPL PENDANT INSERT, 2 SP

Manufacturer: Hubbell Wiring Device-Kellems | Catalog # PG2 | Codale Part # 3284763
$495.53/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Primary Spec Sheet Product Catalog Page Installation / Instruction Manual
Switches and Lighting Controls, Industrial Grade, Pendant Controls, Push Button Station Accessories, Single Speed Replacement Buttons, Pilot Duty, 250V AC Max, Terminal Screws, Black

Technical Information

Actuator
Push Buttons
Amperage
6 Amp
Applications
Single Speed Button Set
Contact Configuration
1 NO, 1 NC, Momentary
Contact Rating
6 A at 120 VAC, 3 A at 240 VAC 35% PF, 1.1 A at 125 VDC, 0.55 A at 250 V Inductive
Indicator
None
Material
Non-Metal
Mounting Type
Cable/Screw Terminal
Number of Phases
1 Phase
Number of Poles
2 Pole
Operating Temperature
-40 degrees C
Size
Full Sized
Standard
UL
Tc Connection
Terminal Screws
Temperature Rating
-40 to 75 degrees C
Type
Full Size, 1-Phase, 2-Pole
Voltage
250 Volt

Manufacturer Information

Brand
Hubbell Wiring Device-Kellems
Sub Brand
Magnetic Starter Controls

General Product Info

12-Digit UPC
783585620015
Color
Black
Product Series
Accessories
Product UPC
78358562001
Weight
0.3 lb

Dimensions

Height
3 Inch
Length
1.9 Inch
Width
3.6 in

Certifications and Compliance

Country of Origin
USA
Features
  • Single speed insert momentary N.O. and N.C.
  • Standard Product
