Burndy YSH2929 Copper Split Compression Wye Tap Connector, 250-2 (4/0-2) (Tap), Provides maximum design and installation flexibility

Manufacturer: Hubbell-Burndy | Catalog # YSH2929 | Codale Part # 3285679
$137.94/ea
ea
Log in or register to view your price, purchase history, and more!
Experiencing long lead times. Please call for availability.
Buy American Compliant Buy American Compliant Primary Spec Sheet
Copper Split Compression Wye Tap Connector, 250-2 (4/0-2) (Tap), Provides maximum design and installation flexibility.

Technical Information

Applications
For High Voltage (15 KV) Power Cables With Copper Conductors
Color Coding
Purple
Conductor Size
2 AWG-250 kcmil
Connection Type
H-Tap
Material
Copper
Plated?
Yes
Plating Type
Tin
Size
1.85 IN Height X 0.9 IN Width X 3 IN Length
Tap Size
4/0, 2/0, 3/0, 2, 1, 1/0 AWG, 250 KCMIL
Type
Taps

Manufacturer Information

Brand
Hubbell Incorporated
Sub Brand
Burndy

General Product Info

12-Digit UPC
781810036969
Product UPC
78181003696
Weight
0.5900 lb

Dimensions

Height
1.85 Inch
Length
3 Inch
Overall Length
3.00 in
Width
0.9 in

Certifications and Compliance

Buy American Compliant
Y
Country of Origin
USA
CSA
No
Features
  • Accommodates a wide range of Run/Tap Copper cable combinations including both flexible and code combinations allowing maximum flexibility
  • Tap grooves function independently from each other, use of one tap is required, balance may be used or left empty
